AST - THS series

Size: 5.6 "(4:3) Display type: TFT color touch screen (LED backlight), 65536 color TFT LCD with LED backlight, Max. colors 16-bit Backlight life (HR): 20000 hours /hrs Working memory (OS): 32M Application memory (AP): 8M Data memory (Data File): 128M 10:N/A 20:128M N/A Serial port: COM1:RS232/422/485 COM2:N/A COM3:RS232 (optional RS485) USB: 1 master host (USB1.0), 1 guest slave (USB2.0) With the net port: 1/2:N/A 4: has (10/100M) Input voltage: 24VDC + 10% Panel size (wide * high, mm) Panel size (w * h, mm): 188.0*143.3 Opening size (wide * high, mm) Cutout dimension (A*B mm): 175.0*132.5

Size: 4.3″ Display type: TTFT color touch screen (LED backlight), 65536 colors TFT LCD with LED Backlight, Max. colors 16-bit (hr) Backlight life: 20000hours /hrs (OS) Working memory: 32M (AP) Program memory: 8M (Data File) Data memory : 128M 10:N/A 20:128M N/A Serial interface: COM1:RS232/422/485 COM2:N/A COM3:RS232（可选RS485） USB : 1 master,1 Slave(USB2.0) Ethernet: 1/2:N/A 4:Yes（10/100M ） Input voltage : 24VDC±10% Panel size(w * h, mm): 130.0*106.2 Cutout dimension(A*B mm) : 119.0*93.0

尺寸 Size: 7″ 显示屏类型 Display type: TFT 彩色触控屏幕（LED背光）, 65536色 TFT LCD with LED Backlight ,Max. colors 16-bit 背光寿命(hr) Backlight life: 20000小时 /hrs 工作内存(OS) Working memory: 64M 应用程序内存(AP) Program memory: 8M 数据内存(Data File) Data memory : 128M 10:N/A 20:128M N/A 串口Serial interface: COM1:RS232/422/485 COM2:N/A COM3:RS232（可选RS485） USB : 1主host（USB1.0),1客slave（USB2.0) 以态网口 Ethernet: 1/2:N/A 4:有（10/100M ） 输入电压 Input voltage : 24VDC±10% 面板尺寸（宽*高,mm) Panel size(w * h, mm): 188.0*143.3 开孔尺寸（宽*高,mm) Cutout dimension(A*B mm) : 175.0*132.5

Size Size: 7" Display type: TFT color touch screen (LED Backlight), 65536 TFT LCD with LED Backlight, max-colors 16-bit Backlight life (hr) Backlight life: 20000 hours/HRS Working memory: 64M Application memory (AP) Program memory: 8M Data memory (Data File) Data memory: 10: N/A fell 8 m Serial interface: rs232/422/485 USB: 1 host (USB1.0),1 passenger slave (USB2.0) Ethernet: 1/2:N/A 4: yes (10/100m) Input voltage: 24VDC + / - 10% Panel size(width * height,mm) Panel size(w * h, mm): 204.4*151.0 Hole size (width * height, mm) Cutout dimension (A * B mm) : 191.5 * 138.0

Size the Size: 4.3" Display type: TFT color touch screen (LED Backlight), 65536 TFT LCD with LED Backlight, max-colors 16-bit Backlight life (hr) Backlight life: 20000 hours/HRS Working memory: 32M Application memory (AP) Program memory: 8M Data File Data memory :128M 10:N/A 20:128m N/A Serial interface: rs232/422/485 USB: 1 host (USB1.0),1 passenger slave (USB2.0) Ethernet: 1/2:N/A 4: yes (10/100m) Input voltage: 24VDC + / - 10% Panel size(width * height,mm) Panel size(w * h, mm): 130.0*106.2 Opening size (width * height,mm) Cutout dimension(A*B mm) : 119.0*93.0

Size Size: 7" Display type: TFT color touch screen (LED Backlight), 65536 TFT LCD with LED Backlight, max-colors 16-bit Backlight life (hr) Backlight life: 20000 hours/HRS Working memory: 64M Application memory (AP) Program memory: 8M Data File Data memory :128M 10:N/A 20:128m N/A Serial interface: rs232/422/485 USB: 1 host (USB1.0),1 passenger slave (USB2.0) Ethernet: 1/2:N/A 4: yes (10/100m) Input voltage: 24VDC + / - 10% Panel size(width * height,mm) Panel size(w * h, mm): 188.0*143.3 Opening size (width * height,mm) Cutout dimension(A*B mm) : 175.0*132.5
