ASK - THE series

Size Size: 7" Display type: TFT color touch screen (LED Backlight), 65536 TFT LCD with LED Backlight, max-colors 16-bit Backlight life (hr) Backlight life: 20000 hours/HRS Working memory: 64M Application memory (AP) Program memory: 8M Data File Data memory :128M 10:N/A 20:128m N/A Serial interface: rs232/422/485 USB: 1 host (USB1.0),1 passenger slave (USB2.0) Ethernet: 1/2:N/A 4: yes (10/100m) Input voltage: 24VDC + / - 10% Panel size(width * height,mm) Panel size(w * h, mm): 188.0*143.3 Opening size (width * height,mm) Cutout dimension(A*B mm) : 175.0*132.5

Size the Size: 4.3" Display type: TFT color touch screen (LED Backlight), 65536 TFT LCD with LED Backlight, max-colors 16-bit Backlight life (hr) Backlight life: 20000 hours/HRS Working memory: 32M Application memory (AP) Program memory: 8M Data File Data memory :128M 10:N/A 20:128m N/A Serial interface: rs232/422/485 USB: 1 host (USB1.0),1 passenger slave (USB2.0) Ethernet: 1/2:N/A 4: yes (10/100m) Input voltage: 24VDC + / - 10% Panel size(width * height,mm) Panel size(w * h, mm): 130.0*106.2 Opening size (width * height,mm) Cutout dimension(A*B mm) : 119.0*93.0

Size：8″    Display type：TFT color touch screen (LED backlight), 65536色 TFT LCD with LED Backlight ,Max. colors 16-bit (hr) Backlight life： 20000hours/hrs (cd/m2) Display contrast：      250:1  Touch panel：   4-wire analog touch panel  Ethernet:      1/2:N/A  4:Yes（10/100M ） Serial interface:     COM1:RS232/RS422/RS485  COM2:N/A   COM3:RS232 （(OptionalRS485） USB:        1 master,1 Slave(USB2.0) (Data File) Data memory        :   1:N/A    2/4:128M Input voltage:      24VDC±10%  Panel size(w * h, mm):     231.5*174.5    Cutout dimension(A*B mm):  221.0*164.0

Size: 7″ Display type: TFT color touch screen (LED Backlight), 65536色 TFT LCD with LED Backlight ,Max. colors 16-bit (hr) Backlight life: 20000小时 /hrs (OS) Working memory: 64M (AP) Program memory: 8M (Data File) Data memory : 128M 10:N/A 20:128M N/A Serial interface: COM1:RS232/422/485 COM2:N/A COM3:RS232（optional RS485） USB : 1 master,1 Slave(USB2.0) Input voltage : 24VDC±10% Panel size(w * h, mm): 188.0*143.3 Cutout dimension(A*B mm) : 175.0*132.5

Size:       10″   Display type:   TFT color touch screen (LED backlight), 65536色 TFT LCD with LED Backlight ,Max. colors 16-bit (hr) Backlight life:      20000 hours  /hrs (OS) Working memory: 32M (AP) Program memory:          8M (Data File) Data memory        :    10:N/A     20:128M    Serial interface:     COM1:RS232/422/485  COM2:N/A   COM3:RS232（可选RS485） USB :  1 master,1 Slave(USB2.0) Ethernet:      1/2: N/A 4: Yes (10/100M) 1/2:N/A 4: Yes (10/100M) Input voltage       :   12-24VDC±10%  Panel size(w * h, mm):   270.1*212.1   Cutout dimension(A*B mm)         :       259.5*201.5
